KERN FKB User Manual

52 TFKB-B-BA-e-2311
14.2 Issue functions
14.2.1 Add-up mode < sum >
With this function the individual weighing values are added into the summation
memory by pressing a button and edited when an optional printer is connected.
Activate function:
 In Setup menu invoke the menu setting < Print >  < sum > and confirm
with button ➔.
 Use the navigation keys  to select the setting < on> and confirm on ➔ but-
ton.
 To exit the menu, press the navigation key  repeatedly
Condition: Menu setting
< prmode >  < trig>  < manual>  <on>
Add-up weighed goods:
 If required, place empty container on scale and tare.
 Place first good to be weighed on balance. Wait until stability display ( ) ap-
pears and then press the PRINT-button. The display changes to < sum1 >, fol-
lowed by the current weighing value. The weighing value is stored and edited by
the printer. The symbol  pops up. Remove the weighed good.
 Place second good to be weighed on balance. Wait until stability display ( )
appears and then press the PRINT-button. The display changes to < sum2 >,
followed by the current weighing value. The weighing value is stored and edited
by the printer. Remove the weighed good.
 Add-up more weighed goods as described above.
 You can repeat this process until the capacity of the scales is exhausted.
Display and edit sum „Total“:
 Press the PRINT key long time. The number of weighings and the total weight are
edited.
The sum memory is deleted; the symbol [..] extinguishes.

KERN FKB Specifications

General

Brand	KERN
Model	FKB
Weighing capacity	6 kg
Weighing range	0 - 6 kg
Readability	0.1 g
Calibration	External
Display	LCD
Weighing units	g, kg, lb, oz
Interface	RS-232
