KERN FKB User Manual

6 TFKB-B-BA-e-2311
KERN
FKB 16K0.1
FKB 16K0.05
FKB 30K1
FKB 36K0.1
Item no./ Type
TFKB 16K-4-B
TFKB 16K-5-B
TFKB 30K-3-B
TFKB 36K-4-B
Readability (d)
0.1 g
0.05 g
1 g
0.1 g
Weighing range (max)
16000 g
16000 g
30000 g
36 kg
Taring range (subtractive)
16000 g
16000 g
30000 g
36 kg
Reproducibility
0.1 g
0.1 g
1 g
0.2 g
Linearity
± 0.3 g
± 0.25 g
± 3 g
± 0.5 g
Stabilization time (typical)
3 s
Smallest part weight for
piece counting - under lab
conditions*
100 mg
50 mg
1 g
100 mg
Smallest part weight for
piece counting - under
normal conditions**
1 g
500 mg
10 g
1 g
Adjustment points
5 / 10 / 15 kg
5 / 10 / 15 kg
10 / 20 / 30 kg
10 / 20 / 30 kg
Recommended adjust-
ment weight, not added
(class)
10 kg; 5 kg;
1 kg (F1)
10 kg; 5 kg;
1 kg (F1)
30 kg (F2)
20 kg + 10 kg
(E2)
Warm-up time
2 h
Weighing Units
kg, g, gn, dwt, ozt, lb, oz, FFA
Humidity of air
max. 80% rel. (non-condensing)
Allowable ambient tempe-
rature
-10 °C ... + 40 °C
Input voltage Appliance
6 V / 1 A
Input voltage Mains adapter
100 V - 240V AC 50 / 60Hz
Batteries (option)
4 x 1,5V AA
Storage battery operation
(optional)
Operating time 48 hrs (backlight off)
Operating time 24 hrs (backlight on)
Loading time approx. 8 hrs.
Auto-Off (battery, re-
chargeable battery)
selectable off, 30s, 1, 2, 5, 30, 60 min
Dimensions housing
350 x 390 x 120 (W x D x H) [mm]
Weighing plate, stainless
steel
340 x 240 (W x D) [mm]
Net weight (kg)
6.5
Interfaces
RS-232 (optional), Ethernet (optional), Bluetooth BLE (v4.0) (optional),
USB-Device (optional), WLAN (optional) via KUP
Underfloor weighing de-
vice
yes (hook supplied)

KERN FKB Specifications

General

Brand	KERN
Model	FKB
Weighing capacity	6 kg
Weighing range	0 - 6 kg
Readability	0.1 g
Calibration	External
Display	LCD
Weighing units	g, kg, lb, oz
Interface	RS-232
