KERN PNJ User Manual

- 25 - PNJ_PNS-SH-e-2011
8.2 Install the AJDP circuit board
Install the AJDP circuit board in the board holder.
 Board holder assy
 Tapping screw 3 mm x 8
 AJDO board assy
 Projections
 Perform final tightening while holding down the board
 The LCD and the window are parallel
 The LCD and the window are not parallel









KERN PNJ Specifications

General

Brand	KERN
Model	PNJ
Category	Scales
Language	English
