56 / 180
Technical data
2017/11
7 Technical data
7.1 Control unit
Weight [kg]
1
Operating voltage [V] 50 Hz
230
Nominal current [A]
Protective rating IP54
Protective class
I
Plug type Earthed connector
Connecting cable [m] 1.4
Required fuse protection C16 A 1 pole
Fuse Fault current circuit breaker
recommended
Microfuse 10 A M
7.2 Pump
Weight [kg]
24
Capacity P1 [kW] 1.5
Speed [rpm]
2900
Operating voltage [V] 50 Hz
230
Nominal current [A] 6.4
Max. pumping capacity [m³/h]
32
Max. pumping height [m] 9.2 m
Max. temperature of material to be
conveyed [°C]
40
Protective rating
IP68, 3mWS/48h
Noise level
<70 dB(dB(A)
Protective class
I
Motor protection internal
Plug type Direct connection
Connection cable 5 m, 3 x 1.5 mm²
Required fuse protection via control unit
C16 A 1 pole
Mode of operation
S3 - 15%
