10
NO.
BLOCK ICON
DEFINITION
1
Returns HIGH or LOW voltage
2
Write digital value to a specific Port.
Digital Output: set the HIGH or LOW output for
IO pins
3
Returns a digital value of a specific Port.
Digital IO Read Pin, generally used to read the
HIGH or LOW level detected by Digital sensor
4
Write analog value between 2 and 255 to a
specific Port.
Analog Output: set the Analog value output by
Analog IO pins (0~255).
