5.Let’s Get Started With Your Projects
Project 1: Hello World
This project is very simple. You can use only a main board and a USB cable to
display the “Hello World!”. It is a communication experiment between the EASY
Plug control board and PC. This is an entry experiment for you to enter the Arduino
Note that need to use a serial communication software, Arduino IDE.
In the above part, you can check the detailed use of Arduino IDE.
EASY plug control board*1
keyestudio EASY plug Control Board V2.0
The processor used in keyestudio EASY plug
control board V2.0 is ATmega328. It has 5
single Digital ports labeled D5 to D9 (of which 3
can be used as PWM outputs), 1 dual-digital
interface (D3-D4), 4 analog inputs (A0-A3), a
Joystick socket (D2-A6-A7), a SPI, a serial port and an IIC communication interface.
Also with a USB connection, a power jack, two ICSP headers and a reset button. It
breaks out the IO ports with RJ11 6P6C plug.
