45
3
Enable IR decoding
4
Print the Infrared signal in RAW types when receiving
it.
5
Sends RAW infrared signals (set the pin number, list,
length of list and IR frequency)
For example:
You need an Arduino Uno board, an IR receiver module and an IR remote control.
Connect the signal pin of IR receiver to Digital pin 3 of Uno board, then upload the code and open the
monitor. If send a signal to an IR receiver module using an IR remote control, you should see the
monitor show the corresponding signal data.
