Keysight Technologies B1500A

27 | Keysight | B1500A Semiconductor Device Analyzer - Configuration Guide
Model/Option Description Qty
B1500A Semiconductor Device
Analyzer Mainframe
1
B1500A-015/ 030 1.5 m or 3 m length of
bundled cables
1
B1500A-A04 Flash memory cell
measurement package
1
B1500A-A5F Test fixture for packaged
device measurement, adds
one 16442B (Optional)
1
B1500A Configuration, continued
Example-7. For flash memory cell characterization (2 pulse channels)
Model/Option Description Qty
B1500A Semiconductor Device
Analyzer Mainframe
1
B1500A-015/ 030 1.5 m or 3 m length of
bundled cables
1
B1500A-A04 Flash memory cell
measurement package
1
B1500A-A25 Adds one HVSPGU and two
SPGU cables
1
16440A SMU/PGU pulse generator
selector
1
16440A-003 Control cable, 40 cm for
second selector
1
B1500A-A5F Test fixture for packaged
device measurement, adds
one 16442B (Optional)
1
Example-8. For flash memory cell characterization (3 or 4 pulse channels)
