Keysight N9927-90001 User’s Guide 371
USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233
Mixed Analyzers))
How to Set Up a USB Antenna
How to Set Up a USB Antenna
This section reviews some general high level steps in setting up a USB antenna
measurement. If you are not familiar with this process or would like more
information on specific EMF measurement setups, refer to:
— SA Mode: “How to Set Up EMF Settings (Requires EMF (Option 358), GPS
(Option 307), and SA Mode (Option 233–Mixed Analyzers))” on page 206
—OTA Mode: “How to Set Up EMF Settings (Requires EMF (Option 358))” on
page 315
USB Antenna Setup Procedure
1. Select the mode and set up your measurement. Refer to Chapter 12,
“Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF
Option 377 (CPU2 Only)” or to Chapter 9, “SA (Spectrum Analyzer) Mode”.
2. Connect a USB antenna. Refer to Figure 14-1.
3. Importing and selecting the X/Y/Z antenna factors:
a. OTA – 5G NR and SA Mode:
Press System
> Utilities> USB Antennas
IMPORTANT! See also, “Alignments” on page 180, in NA mode,Chapter 9,
“SA (Spectrum Analyzer) Mode,” and Chapter 10, “RTSA (Real-Time
Spectrum Analyzer) Mode—Option 350 (CPU2 Only)” mode.
If necessary, this step can be skipped and done after the USB antenna is
set up.
Only Agos Advanced Technologies SDIA–6000 Triaxial Lsotropic USB
antenna is compatible with EMF (Option 358). See also Chapter 9, “SA
(Spectrum Analyzer) Mode” and Chapter 12, “Over–the–Air Measurements
(OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only)”.
