526 Keysight N9927-90001 User’s Guide
Channel Scanner (Option 312)
How to Set Up Channel Scanner
— Then File Type
— KML (default) or
— CSV
— Then Save Log File
.
6. Export KML file into 3rd party mapping software (i.e., Google or Google
Earth)
How to Define a Channel and Use Channel Scanner
Channel definitions consist of the following:
— Each channel is defined by CF and Integration BW.
— Frequency span is set automatically to 1.5 x Integration BW
— Power is measured over the Integration BW
Using Channel Scanner, refer to:
— “Step 1A: Scan Mode: Range Channel Defined” on page 527 or
— “Step 1B: Scan Mode: Custom List Channel Defined” on page 528
Then:
— “Step 2: Select Display Type” on page 529
— “Step 3. Modify Scale and the Display Color Bar Settings” on page 533
— “Step 4: Enable Data Logging and Record Results” on page 534
— “Step 5: Save the Log Results:” on page 536
— “Step 6: Import and Play back KML Files into 3rd Party Software (Example:
Google Earth with Animation Tool)” on page 536
