282 Keysight N9927-90001 User’s Guide
IQ Analyzer (IQA) – Option 351 (CPU2 Only)
Trace Display States (IQA Mode)
—MinHold Displays the minimum response of the input signal at each
data point over multiple acquisitions. See also Average Count in
“Adjusting the Measurement Setup Settings” on page 270.
—Average
Each data point is averaged over multiple acquisitions as set
by the Average Count setting. Learn more in “Adjusting the
Measurement Setup Settings” on page 270.
—View
Displays and then holds the last complete measurement trace on
the screen. This is similar to storing a trace in memory.
—Blank
Displays no trace.
