360 Keysight N9927-90001 User’s Guide
5G Rapid Prototype Phased Array Antenna – Option 360
How to Record/Playback (Option 360)
Figure 17 Field Strength Annotation that can be Recorded and Played Back
How to Record
—Press Measure
—Then Data Logging
If Recording or Playback is not occurring when you think it should, check
the following:
— Is the sweep in HOLD? (upper-left annotation), or check the Sweep
menu for Continuous set to OFF.
— Is Recording or Playback Paused? (mid-left annotation)
— Is the Record or Playback Interval set too long? (Configuration
settings.)
Record-Play files are saved to:
— Record-Play files are save-recalled to:
"[CurrentDevice]\RecordPlayback\PAA\"
