Keysight N9927-90001 User’s Guide 435
Interference Analyzer (SA Mode) – Option 236
Record/Playback (SA Option)
SA Data Recording:
— Data can be recorded at the Raw Meas block where data is acquired after
ResBW, VideoBW, and Detector processing, but before any trace state
processing.
— Data can be recorded from Traces 1,2,3, or 4 which includes the trace state
(Max Hold, Min Hold, and so forth).
— Recording from a Clear/Write trace yields exactly the same data as
recording from the Raw Meas block.
— Data is ALWAYS played back at the same location in the data flow: just after
the Raw Meas block, through all currently active Traces, and onto the
display.
— See an example using Record Playback with Max Hold traces in “Record
Playback Example (SA Only)” on page 436.
Playback Configuration
By default, trace sweeps are played back as fast as the trace can be drawn on
the screen. The following setting allows you to slow playback. In addition, you
can manually scroll through individual traces using Playback Trace, or scroll
through State and User Tags using Playback State/Tag. Learn more in How to
Playback a Session in “How to Playback a Session” on page 431.
To slow playback of a session:
— Record a new session or Open an existing session.
—Press Playback Configuration
—Then Playback Interval
— Enter a value in seconds between 0 (no delay) and 100 using the
numeric keypad, arrows, or the rotary knob. After using the
keypad, select a multiplier key. Learn about multiplier abbreviations.
—Press Enter
— First Trace to define the first trace in a Range of traces to be
recorded/played/saved.
— Last Trace
to define the last trace in a Range of traces to be
recorded/played/saved.
— Back
to return to the previous menu.
Manage Sessions
—Press Trace 6
—Then Record Playback
To Next Page
