406 Keysight N9927-90001 User’s Guide
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on
N991xB), GPS (Option 307) and GPS Receiver (Option 307))
How to Record/Playback (Option 352)
Figure 15-22 Field Strength Annotation that can be Recorded and Played Back
How to Record
—Press Measure
—Then Data Logging
If Recording or Playback is not occurring when you think it should, check
the following:
— Is the sweep in HOLD? (upper-left annotation), or check the Sweep menu
for Continuous
set to OFF.
— Is Recording or Playback Paused? (mid-left annotation)
— Is the Record or Playback Interval set too long? (Configuration settings.)
Record-Play files are saved to:
— Record-Play files are save-recalled to:
"[CurrentDevice]\RecordPlayback\Maps\"
