Keysight CXG, EXG, and MXG X-Series Signal Generators Programming Guide 221
Creating and Downloading Waveform Files
Non–volatile Storage memory where files survive cycling the signal
generator power. Files remain until overwritten or
deleted. To play back waveforms after cycling the signal
generator power, you must load waveforms from non–
volatile (NVWFM) to volatile (WFM1). On the Keysight
X-Series signal generators the non–volatile memory is
referred to as internal media and external media. The
following file types share this memory:
The following figure on Figure 5-1 on page 222 shows the locations within the
signal generator for volatile and non–volatile waveform data.
Table 5-2 Signal Generators and Non–Volatile Memory Types
Non–Volatile Memory Type Signal Generator Model
N5166B, N5172B, N5182B with
an installed BBG option
I/Q x
Marker x
File header x
Sweep List x
User Data x
User PRAM x
Instrument State x
Waveform Sequences
(multiple I/Q files played
together)
x
