250 Keysight CXG, EXG, and MXG X-Series Signal Generators Programming Guide
Creating and Downloading Waveform Files
Using the Download Utilities
Using the Download Utilities
Keysight provides free download utilities to download waveform data into the
signal generator. The table in this section describes the capabilities of three
such utilities.
For more information and to install the utilities, refer to the following URLs:
— Keysight Signal Studio Toolkit 2:
http://www.keysight.com/find/signalstudio
This software provides a graphical interface for downloading files.
— Keysight Waveform Download Assistant:
http://www.keysight.com/find/downloadassistant
This software provides functions for the MATLAB environment to download
waveform data.
Table 5-13
Features Keysight Signal
Studio Toolkit 2
Keysight
Waveform
Download
Assistant
Downloads encrypted waveform files X
Downloads complex MATLAB waveform data X
Downloads MATLAB files (.mat) X
Downloads unencrypted interleaved 16–bit I/Q files
a
X
Interleaves and downloads earlier 14–bit E443xB I and Q files X
Swaps bytes for little endian order
Manually select big endian byte order for 14–bit and 16–bit I/Q
files
X
Downloads user–created marker files X X
Performs scaling X X
Starts waveform play back X X
Sends SCPI Commands and Queries X X
Builds a waveform sequence X X
a. ASCII or binary format.
