Keysight CXG, EXG, and MXG X-Series Signal Generators Programming Guide 325
Creating and Downloading User–Data Files
Signal Generator Memory
Checking Available Memory
Whenever you download a user–data file, you must be aware of the amount of
remaining signal generator memory. Table 6-5 shows to where each user–data
file type is downloaded and from which memory type the signal generator
accesses the file data. Information on downloading a user–data file is located
within each user–data file section.
Table 6-4 Maximum Signal Generator Memory
Volatile (WFM1/PRAM) Memory Non–Volatile (NVWFM) Memory
Option Size Option Size
N5166B
653, 655 (BBG) 32 MSa (160 MB) Standard
009
600 MSa (3 GB)
7.5 GSa (30 GB)
022 512 MSa (2.5 GB) USB Flash Drive (UFD) user determined
N5172B and N5182B
653, 655, 656,
657 (BBG)
32 MSa (160 MB) Standard
006
009
600 MSa (3 GB)
2 GSa (8 GB)
7.5 GSa (30 GB)
021 (72B only)
022
023 (82B only)
256 MSa (1.25 GB)
512 MSa (2.5 GB)
1024 MSa (5 GB)
USB Flash Drive (UFD) user determined
The FIR filter (file) types only apply to vector signal generator models with
an installed baseband generator option.
