224 Keysight CXG, EXG, and MXG X-Series Signal Generators Programming Guide
Creating and Downloading Waveform Files
Memory Size
The amount of available memory, volatile and non–volatile, varies by the
installed options and by amount of memory used by other files that share the
memory. When we refer to waveform files, we state the memory size in
samples (one sample equals five bytes). The waveform playback memory
resides on the baseband generator that is installed in the Keysight X-Series
signal generator. Refer to Table 5-4 on page 224 for the maximum available
memory for each model and option.
128 MB – 255 MB 4K
256 MB – 511 MB 8K
512 MB – 1023 MB 16K
1024 MB – 2048 MB 32K
2048 MB – 4096 MB 64K
4096 MB – 8192 MB 128K
8192 MB – 16384 MB 256K
Table 5-3 Drive Size (logical volume)
Drive Size (logical volume) Cluster Size (Bytes)
(Minimum Allocation Size)
Table 5-4 Maximum Signal Generator Memory
Volatile (BBG) Memory Non–Volatile (Internal Storage and USB Media)
Memory
Option Size Option Size
N5166B
653, 655 (BBG) 32 MSa (160 MB) Standard
009
600 MSa (3 GB)
7.5 GSa (30 GB)
022 512 MSa (2.5 GB) USB Flash Drive (UFD) user determined
N5172B and N5182B
653, 655, 656, 657
(BBG)
32 MSa (160 MB) Standard
006
009
600 MSa (3 GB)
2 GSa (8 GB)
7.5 GSa (30 GB)
021 (N5172B only)
022
023 (N5182B only)
256 MSa (1.25 GB)
512 MSa (2.5 GB)
1024 MSa (5 GB)
USB Flash Drive (UFD) user determined
