60 Keysight CXG, EXG, and MXG X-Series Signal Generators Programming Guide
Using IO Interfaces
Using USB
Front Panel USB (Type–A)
For details on using the front panel USB (Type–A) and the front panel USB
Media operation, refer to the User’s Guide.
Verifying USB Functionality
Mini–B 5 Pin Rear Panel Connector
Type–A Front Panel USB Connector
For details on using the front panel USB (Type–A) and the front panel USB
Media operation, refer to the User’s Guide.
Table 2-1 USB Interface Cable
Quantity Description Keysight Part Number
1 USB cable Mini–B 5 pin to Type–A 82357–61601
For information on verifying your Mini–B 5 pin USB (rear panel)
functionality, refer to the Keysight Connection Expert in the Keysight IO
Libraries Help. The Keysight IO libraries are included with your signal
generator or Keysight GPIB interface board, or they can be downloaded
from the Keysight website: http://www.keysight.com.
