Keysight CXG, EXG, and MXG X-Series Signal Generators Programming Guide 229
Creating and Downloading Waveform Files
Commands for Downloading and Extracting Waveform Data
SCPI/non–volatile
memory
a
MEM:DATA:UNPRotected "/user/waveform/file_name",<blockdata>
MEM:DATA:UNPRotected "/user/markers/file_name",<blockdata>
MEM:DATA:UNPRotected "/user/header/file_name",<blockdata>
MEM:DATA:UNPRotected "NVWFM:file_name",<blockdata>
MEM:DATA:UNPRotected "NVMKR:file_name",<blockdata>
MEM:DATA:UNPRotected "NVHDR:file_name",<blockdata>
MEM:DATA:UNPRotected "file_name@NVWFM",<blockdata>
MEM:DATA:UNPRotected "file_name@NVMKR",<blockdata>
MEM:DATA:UNPRotected "file_name@NVHDR",<blockdata>
FTP/volatile memory
b
put <file_name> /user/bbg1/waveform/<file_name>
put <file_name> /user/bbg1/markers/<file_name>
put <file_name> /user/bbg1/header/<file_name>
FTP/non–volatile
memory
b
put <file_name> /user/waveform/<file_name>
put <file_name> /user/markers/<file_name>
put <file_name> /user/header/<file_name>
a. The :MEM:DATA:UNPRotected command is not required to be able to extract files (i.e.
use :MEM:DATA). For more information, refer to the SCPI Command Reference.
b. See “FTP Procedures” on page 231.
Table 5-8 Extracting Unencrypted I/Q Data
Download
Method/Memory
Type
Command Syntax Options
SCPI/volatile
memory
MMEM:DATA? "/user/bbg1/waveform/<file_name>"
MMEM:DATA? "WFM1:<file_name>"
MMEM:DATA? "<file_name>@WFM1"
SCPI/non–volatile
memory
MMEM:DATA? "/user/waveform/<file_name>"
MMEM:DATA? "NVWFM:<file_name>"
MMEM:DATA? "<file_name>@NVWFM"
FTP/volatile
memory
a
get /user/bbg1/waveform/<file_name>
get /user/bbg1/markers/<file_name>
get /user/bbg1/header/<file_name>
FTP/non–volatile
memory
a
get /user/waveform/<file_name>
get /user/markers/<file_name>
get /user/header/<file_name>
a. See “FTP Procedures” on page 231.
Table 5-7 Downloading Unencrypted Files for Extraction
Download Method/
Memory Type
Command Syntax Options
