Keysight CXG, EXG, and MXG X-Series Signal Generators Programming Guide 233
Creating and Downloading Waveform Files
Commands for Downloading and Extracting Waveform Data
To get a file, type:
get /user/waveform/<file_name1> <file_name>
where <file_name1> is the file to download from the signal generator’s
/user/waveform/ directory and <file_name> is the name designator for
the local PC/UNIX.
— If a marker file is associated with the data file, use the following
command to download it to the local PC/UNIX directory:
get /user/markers/<file_name1> <marker file_name>
where <marker file_name1> is the name of the marker file to
download from the signal generator’s /user/markers/ directory
and <marker file_name> is the name of the file to be downloaded
to the local PC/UNIX.
For more examples of get command usage refer to Table 5-12.
6. At the ftp prompt, type: bye
7. At the command prompt, type: exit
Using the Signal Generator’s Internal Web Server
1. Enter the signal generator’s hostname or IP address in the URL.
http://<host name> or <IP address>
2. Click the Signal Generator FTP Access button located on the left side of
the window.
Correct put
<filename.wfm>
put
<filename.mkr>
/user/waveform/<filename
1>
/user/marker/<filename1>
Creates a waveform
file and a
compatible marker
file.
Table 5-11 Put Command Examples
Command
Results
Local Remote Notes
Table 5-12 Get Command Examples
Command
Results
Local Remote Notes
Incorrect get
/user/waveform/file
get /user/marker/file
file1
file1
Results in file1 containing only the
marker data.
Correct get
/user/waveform/file
get /user/marker/file
file1.wfm
file1.mkr
Creates a waveform file and a
compatible marker file. It is easier to
keep files associated by varying the
extenders.
