Base Matrix Configuration 2
Keysight 34934A User’s Guide 205
34934A Module D-Sub Connectors: 16x32 Wiring
When wiring directly to the 34934A’s D-Sub connectors, you must make the
following connections—in addition to row and column connections—to configure
the 16x32 matrix:
Module Configuration:
The 96 connections listed in the two tables below (64
here; 32 in the table on the following page) are required to create the 16x32
matrix.
In the first table, note the AND indicating that you must short all connections
shown. In the second table, note the OR indicating that for each line in the table,
you must short one set of pins or the other, but not both.
C3 13 C11 31 C19 55 C27 63 IL1 61
R13 22 C3 14 C11 32 C19 56 C27 64 IL2 40
R14 42 C4 17 C12 33 C20 57 C28 65
R15 2 C4 18 C12 34 C20 58 C28 66
R16 4 C5 7 C13 35 C21 43 C29 67
C5 8 C13 36 C21 44 C29 68
C6 11 C14 37 C22 45 C30 69
C6 12 C14 38 C22 46 C30 70
C7 15 C15 23 C23 49 C31 71
C7 16 C15 24 C23 50 C31 72
C8 19 C16 29 C24 51 C32 75
C8 20 C16 30 C24 52 C32 76
Description Pin Description Pin Description Pin Description Pin Description Pin Description Pin
To Next Page
