58 Keysight E4980A/E4980AL Precision LCR Meter
Troubleshooting
Function Specific Troubleshooting
4-
Figure 4-13 Switches Setting
㪼㪋㪐㪏㪇㪸㫊㪼㪈㪇㪌㪉
10
10
㪦㪥㪦㪝㪝
㪪㪉
㪦㪥㪦㪝㪝
㪪㪈
Table 4-8 Setting Bit Switch (S1)
Bit Default
1
1
On
2
1
Off
3
1
Off
4On
1. For bits 1 to 3 of bit switch S1, only one bit can be turned on at one
time.
Table 4-9 Setting Bit Switch (S2)
Bit Default
1-8 On
To Next Page
