12 | Keysight | E5071C Network Analyzer - Conguration Guide
1. Special rugged female connector specically for connecting to the
network analyzer test port, but does not mate with a standard male con-
nector.
2. 1250-1744 3.5 mm (f) to 50 Ω Type-N (m) adapters are recommended to
connect to the E5071C Option x4x, x6x, and x8x test ports, which have
Type-N (f) connectors.
3. NMD-3.5 mm (f) to 3.5 mm (f), or 3.5 mm (f) to 3.5 mm (f) adapters are
recommended to connect to the E5071C Option xD5, xK5, which have
NMD-3.5 mm (m) connectors.
4. Consider purchasing Keysight 20mm TORQUE WRENCH 8710-1764
N4433A-xxx mixed-connector options:
Connector
type
Port A
option
Port B
option
Port C
option
Port D
option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
– N4691B Microwave ECal: 300 kHz to 26.5 GHz, 2 ports.
Includes:
Option M0F module with:
N4691-60001 3.5 mm (f) to 3.5 mm (m) ECal module
Option 00M module with:
N4691-60002 3.5 mm (m) to 3.5 mm (m) ECal module
Option 00F module with:
N4691-60003 3.5 mm (f) to 3.5 mm (f) ECal module
Option 00A adds:
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Cables
– 1150 0E
2, 3, 4
cable, APC 3.5 mm (m), DC to 26.5 GHz
Includes: one 610 mm (24 in) with male connectors.
– 1150 0F
2, 3, 4
150 cm cable, APC 3.5 mm (m), DC to 26.5 GHz
Includes: one 1520 mm (60 in) with male connectors.
– 85131C
1, 4
single, semi-rigid:
3.5 mm (f) to PSC-3.5 mm (f), 81 cm, 32 inches
– 85131D
1. 4
set, semi-rigid:
85131-60009 one 3.5 mm (f) to 3.5 mm (m), 53 cm,
21 inches,
– 85131-60010 one 3.5 mm (f) to PSC-3.5 mm (f), 53 cm,
21 inches
– 85131E
1, 4
single, exible: 3.5 mm (f) to PSC-3.5 mm (f),
96.5 cm, 38 inches
– 85131F
1, 4
set, exible:
– 85131-60012 one 3.5 mm (f) to 3.5 mm (m), 62.2 cm,
24.5 inches
– 85131-60013 one 3.5 mm (f) to PSC-3.5 mm (f), 62.2 cm,
24.5 inches
– 85131G
1, 4
single, semi-rigid: 3.5 mm (f) to 3.5 mm (m),
53 cm, 21 inches
– 85131H
1, 4
single, exible: 3.5 mm (f) to 3.5 mm (m), 62.2 cm,
24.5 inches
– 85134C
1
single, semi-rigid: PSC-3.5 mm (f) to 2.4 mm (f),
81 cm, 32 inches
– 85134D
1
set, semi-rigid:
– 85134-60002 one 2.4 mm (f) to PSC-3.5 mm (f), 53 cm,
21 inches
– 85134-60001 one 2.4 mm (f) to PSC-3.5 mm (m), 53 cm,
21 inches
– 85134E
1
single, exible: PSC-3.5 mm (f) to 2.4 mm (f),
96 cm, 38 inches
– 85134F
1
set, exible:
85134-60004 one 2.4 mm (f) to PSC-3.5 mm (f), 61 cm,
24 inches
85134-60003 one 2.4 mm (f) to PSC-3.5 mm (m), 61 cm,
24 inches
– 85134G
1
single, semi-rigid: 2.4 mm (f) to PSC-3.5 mm (m),
53 cm, 21 inches
– 85134H
1
single, exible: 2.4 mm (f) to PSC-3.5 mm (m),
61 cm, 24 inches
– N4419AK20 single, exible: 3.5 mm (m) to 3.5 mm (f),
91.4 cm, 36 inches
– Z5623A-K20 single, exible: 3.5 mm (m) to 3.5 mm (m),
91.4 cm, 36 inches
Adapters
– 11853A 50 Ω Type-N accessory kit.
Includes:
1250-1472 Type-N (f) to Type-N (f) adapter (two included)
1250-1475 Type-N (m) to Type-N (m) adapter (two included)
85032-60009 Type-N (f) short
85032-60008 Type-N (m) short
– 11878A Type-N to 3.5 mm adapter kit.
Includes:
1250-1744 3.5 mm (f) to 50 Ω Type-N (m) adapter
1250-1743 3.5 mm (m) to 50 Ω Type-N (m) adapter
1250-1745 3.5 mm (f) to 50 Ω Type-N (f) adapter
1250-1750 3.5 mm (m) to 50 Ω Type-N (f) adapter
– 11524A 7 mm to Type-N (f) adapter
– 11525A 7 mm to Type-N (m) adapter
– 85130C
1
3.5 mm to Type-N
Includes:
85054-60029 NMD-3.5 mm to Type-N (f)
85054-60030 NMD-3.5 mm to Type-N (m)
– 85130D
1
3.5 mm to 3.5 mm
Includes:
85130-60005 NMD-3.5 mm to PSC-3.5 mm (f)
85130-60006 NMD-3.5 mm to PSC-3.5 mm (m)
– 85130F
1
2.4 mm to 3.5 mm
