11 | Keysight | E5071C Network Analyzer - Conguration Guide
For devices with 3.5 mm or SMA connectors
Mechanical calibration kits
– 85033E economy: DC to 9 GHz. Includes:
85033-60016 3.5 mm (m) load
85033-60017 3.5 mm (f) load
85033-60018 3.5 mm (m) open
85033-60019 3.5 mm (f) open
85033-60020 3.5 mm (m) short
85033-60021 3.5 mm (f) short
8710-1761 torque wrench
Option 85033E-100 adds:
85027-60005 3.5 mm (f) to 3.5 mm (f) adapter
Option 85033E-200 adds:
85027-60007 3.5 mm (m) to 3.5 mm (m) adapter
Option 85033E-300 adds:
85027-60006 3.5 mm (m) to 3.5 mm (f) adapter
Option 85033E-400 adds:
1250-1744 3.5 mm (f) to 50 Ω Type-N (m) adapter
1250-1743 3.5 mm (m) to 50 Ω Type-N (m) adapter
1250-1745 3.5 mm (f) to 50 Ω Type-N (f) adapter
1250-1750 3.5 mm (m) to 50 Ω Type-N (f) adapter
Option 85033E-500 adds:
1250-1746 3.5 mm (m) to 7 mm adapter (two included)
1250-1747 3.5 mm (f) to 7 mm adapter (two included)
– 85052C precision TRL: DC to 26.5 GHz. Includes:
00902-60003 3.5 mm (m) xed load
00902-60004 3.5 mm (f) xed load
85052-60006 3.5 mm (m) short
85052-60007 3.5 mm (f) short
85052-60008 3.5 mm (m) open
85052-60009 3.5 mm (f) open
85052-60032 3.5 mm (f) to 3.5 mm (f) adapter
85052-60033 3.5 mm (m) to 3.5 mm (m) adapter
85052-60034 3.5 mm (f) to 3.5 mm (m) adapter
85052-60035 3.5 mm short TRL line
85052-60036 3.5 mm long TRL line
– 85052D economy: DC to 26.5 GHz. Includes:
00902-60003 3.5 mm (m) xed load
00902-60004 3.5 mm (f) xed load
85052-60006 3.5 mm (m) short
85052-60007 3.5 mm (f) short
85052-60008 3.5 mm (m) open
85052-60009 3.5 mm (f) open
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Electronic calibration kits
– 85093C RF ECal: 300 kHz to 9 GHz, 2 ports
Standard module includes:
Option M0F with:
85093-60008 3.5 mm (f) to 3.5 mm (m) ECal module
Option 00F module with:
85093-60010 3.5 mm (f) to 3.5 mm (f) ECal module
Option 00M module with:
85093-60009 3.5 mm (m) to 3.5 mm (m) ECal module
Option 00A adds:
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
85093C-xxx mixed-connector options:
Port A option Port B option
Type (f) (m) Type (f) (m) Type (f) (m)
3.5 mm 101 102 Type-N 203 204 7-16 205 206
– N4431B Microwave ECal: 9 kHz to 13.5 GHz, 4 ports
1
Includes:
Option 010 module with:
N4431-60006 4 x 3.5 mm (f) ECal module
N4431B-xxx mixed-connector options:
Connector
type
Port A
option
Port B
option
Port C
option
Port D
option
3.5 mm 201 301 401
3.5 mm (m) 102 202 302 402
Type-N
50 Ω (f)
103 203 303 403
Type-N
50 Ω (m)
104 204 304 404
7-16 (f ) 105 205 305 405
7-16 (m) 106 206 306 406
– N4433A Microwave ECal: 300 kHz to 20 GHz, 4 ports
Includes:
Option 010 module with:
N4433-60003 4 x 3.5 mm (f) ECal module
1. Performance from 9 kHz to 300 kHz is valid only for the E5071C ENA
network analyzer with rmware version A.09.10 or higher.
