04 | Keysight | E5071C Network Analyzer - Conguration Guide
E5071C ENA Network Analyzer
Options
To add options to a product, order the corresponding item number.
Option
1
Description Additional information
Test set
Option 240
Option 440
Option 245
Option 445
Option 260
Option 460
Option 265
Option 465
Option 280
Option 480
Option 285
Option 485
2-port test set, 9 kHz to 4.5 GHz without bias tees
4-port test set, 9 kHz to 4.5 GHz without bias tees
2-port test set, 100 kHz to 4.5 GHz with bias tees
4-port test set, 100 kHz to 4.5 GHz with bias tees
2-port test set, 9 kHz to 6.5 GHz without bias tees
4-port test set, 9 kHz to 6.5 GHz without bias tees
2-port test set, 100 kHz to 6.5 GHz with bias tees
4-port test set, 100 kHz to 6.5 GHz with bias tees
2-port test set, 9 kHz to 8.5 GHz without bias tees
4-port test set, 9 kHz to 8.5 GHz without bias tees
2-port test set, 100 kHz to 8.5 GHz with bias tees
4-port test set, 100 kHz to 8.5 GHz with bias tees
Test port connector: Type-N (f)
Option 2D5
Option 4D5
Option 2K5
Option 4K5
2-port test set, 300 kHz to 14 GHz with bias tees
4-port test set, 300 kHz to 14 GHz with bias tees
2-port test set, 300 kHz to 20 GHz with bias tees
4-port test set, 300 kHz to 20 GHz with bias tees
Test port connector: 3.5 mm (m)
5
Time base
Option UNQ
Option 1E5
Standard stability time base
High stability time base Adds a higher stability time base reference.
Hard disk drive
Option 017
Option 019
Removable hard disk drive
Standard hard disk drive
Additional features
Option 008
2
Option TDR
3
Option 010
Option 790
4
Frequency offset mode
Enhanced time domain analysis
Time domain analysis
Measurement wizard assistant software
Adds frequency-offset sweep and harmonic measurement capabilities.
Adds time domain transform, gating capabilities and graphical user
interface to simplify time domain measurements.
Adds time domain transform and gating capabilities.
Adds Measurement Wizard Assistant (MWA) software to simplify your
multiport measurements with the 4-port ENA
Accessories
Option 1CM
Option 1CN
Option 1CP
Option 810
Option 820
Rack mount kit
Front handle kit
Rack mount and front handle kit
Add keyboard
Add mouse
Adds a rack mount kit (part number: 1CM015A) for use without
handles.
Adds a front handle kit (part number: 1CN005A).
Adds a rack mount and front handle kit (part number: 1CN009A).
Calibration documentation
Option 1A7
Option A6J
ISO 17025 compliant calibration
ANSI Z540 compliant calibration
1. Options are ordered using the combined model/option number, e.g. E5071C-240.
2. Order the 82357B USB/GPIB interface at the same time if you want to control power meters with the E5071C. This will allow you to conduct scalar mixer
calibrations (SMC), power calibrations, or receiver calibrations after power calibrations.
3. Option TDR is a superset of Option 010. Option TDR and Option 010 are mutually exclusive options and there is no need to purchase both options.
4. When using an ECal module with the MWA calibration wizard, a 4-port ECal module (i.e. N4431B, N4433A) is required.
5. Consider purchasing Keysight 20mm TORQUE WRENCH 8710-1764
