Keysight M8000 Series of BER Test Solutions Installation Guide 67
Installing Modules 2
The following figure displays the M9537A Embedded Controller installed in
slot 1 of the M9505A AXIe chassis.
Figure 51 M9537A embedded controller with M8009A and M8042A
Detailed information and user guide for the M9537A Embedded Controller
module is available at www.keysight.com/find/M9537A.
The M9537A Embedded Controller module will successfully connect with
M8050A only when installed in slot 1 of the M9505A/M9506A chassis. Make
sure that you install the module in the M8050A before powering up the
complete setup.
You should not connect the M8050A to multiple operating host computers at
the same time. If you plan to use the M9537A AXIe Embedded Controller as the
host computer, then do not connect an external host computer to the M8050A.
