Keysight N777 C Series - Trigger:configuration

88 Keysight N777xC Series Tunable Laser Family Programming Guide
4 Measurement Operations & Settings
Response: DISabled:
STFinished:
SWFinished:
SWSTarted:
Never.
When a sweep step finishes.
When sweep cycle finishes.
When a sweep cycle starts.
Example: :trig0:outp? -> dis
Affects: All tunable laser modules
Command: :TRIGger:CONFiguration
Syntax: :TRIGger:CONFiguration
Description: Sets the hardware trigger configuration with regard to Output and Input Trigger Connectors.
Parameters: 0 or DISabled:
1 or DEFault:
2 or PASSthrough:
3 or LOOPback:
Trigger connectors are disabled.
The Input Trigger Connector is activated, the incoming trigger response for each
slot.
A trigger at the Input Trigger Connector generates a trigger at the Output Trigger
Connector automatically. No triggers from the instrument at the output.
The same as PASSthrough. This is included for compatibility reasons.
Response: none
Example: :trig:conf dis
affects All modules
Command: :TRIGger:CONFiguration?
Syntax: :TRIGger:CONFiguration?
Description: Returns the hardware trigger configuration.
Parameters: None
Parameters: 0 or DISabled:
1 or DEFault:
2 or PASSthrough:
3 or LOOPback:
Trigger connectors are disabled.
The Input Trigger Connector is activated, the incoming trigger response for each slot.
A trigger at the Input Trigger Connector generates a trigger at the Output Trigger
Connector automatically. No triggers from the instrument at the output.
The same as PASSthrough. This is included for compatibility reasons.
Example: :trig:conf?
-> DEF
affects All modules
