Keysight N9020B - 6.9.1.54 Mixing Mode; 6.9.1.55 Match State

6 Input/Output
6.9 Calibration
Couplings Coupled with "Phase Noise Optimization" on page 2300. When this parameter is ON, it selects all
available LO mappings, and Phase Noise Optimization parameter displays All in the Configuration
table. When this parameter is OFF, the Phase Noise Optimization parameter displays its previously set
value in the Configuration table
Preset
OFF
State Saved Saved in instrument state
Range
ON|OFF
6.9.1.54 Mixing Mode
Determines the LO Mixing Mode to be used.
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:LO:MMODe NORMal | ALTernate | ALL
:SYSTem:CALibration:ROW[1]|2|…|100:LO:MMODe?
Example
:SYST:CAL:ROW3:LO:MMOD NORM
Dependencies The SCPI command applies to the current selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-
221,Settings conflict; Subopcode does not reference an existing Cal row” is generated
Preset
NORMal
State Saved Saved in instrument state
Range
NORMal|ALTernate|ALL
6.9.1.55 Match State
Determines if the Cal settings must match exactly when applying the correction. If
not, the system may find the closest matching state or interpolate between states.
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:MATCh[:STATe] ON | OFF | 1 | 0
:SYSTem:CALibration:ROW[1]|2|…|100:MATCh[:STATe]?
Example
:SYST:CAL4:MATC ON
:SYST:CAL4:MATC?
Dependencies The SCPI command is applied to the currently selected Cal Group. The subopcode is used to identify
the Cal row in the Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Preset All True
State Saved Saved in instrument state
Range True | False
Vector Modulation Analyzer Mode User's &Programmer's Reference 2306
