7 Save/Recall/Print
7.3 Save
7,0.94868,0.31623,7
8,-0.94868,-0.31623,8
9,-0.31623,-0.31623,9
10,0.31623,-0.31623,A
11,0.94868,-0.31623,B
12,-0.94868,-0.94868,C
13,-0.31623,-0.94868,D
14,0.31623,-0.94868,E
15,0.94868,-0.94868,F
7.3.59 Sync Pattern
Selects a file to which to export the sync pattern string.
Sync Pattern files are CSV files, and contain the sync pattern string in a form that
can be imported into Excel or similar spreadsheets, as well as header data that gives
information on the sync pattern data.
The default path for Sync Pattern files is:
My Documents\VMA\DDEMOD\SyncPattern
Sync Pattern files have the extension .csv. The default filename is SyncPattern_
0000.csv, where the 4-digit number is the lowest number that does not conflict
with any filename in the current directory.
See .csv sync pattern file format
Remote Command
:MMEMory:STORe:DDEMod:SYNC:PATTern <filename>
Example Save the sync pattern data to the file mySyncPattern2.csv in the current path:
:MMEM:STOR:DDEM:SYNC:PATT "mySyncPattern2.csv"
Notes If the save is initiated via SCPI, and the file already exists, the file will be overwritten
Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an
instrument software upgrade
Both single and double quotes are supported for any filename parameter over SCPI
Dependencies Only appears in VMA Mode, in the Digital Demod measurement
Status Bits/OPC
dependencies
Sequential - waits for previous measurement to complete
Backwards
Compatibility SCPI
:MMEMory:STORe:SYNC:PATTern <filename>
.csv sync pattern file format
Except for information in quotes, sync pattern files are not case sensitive.
Information in bold is required verbatim; other text is example text, and italic text is
commentary which should not be present in the file.
Vector Modulation Analyzer Mode User's &Programmer's Reference 2411
