Keysight N9020B - Advanced; Symbol Time Adjustment

3 VMA Mode
3.2 Custom OFDM Measurement
Preset 0.8
State Saved Saved in instrument state
Min 0
Max 1
Transition Bandwidth
Enables you to specify the transition bandwidth for either Remez or Windowed Sinc
filtering as a fraction of the OFDM System Sample Frequency.
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7:FILTer:TBANd <double>
[:SENSe]:OFDM:CCARrier0|…|7:FILTer:TBANd?
Example
:OFDM:CCAR0:FILT:TBAN 0.1
:OFDM:CCAR0:FILT:TBAN?
Preset 0.1
State Saved Saved in instrument state
Min 0
Max 1
Advanced
Contains advanced formatting functions.
Symbol Time Adjustment
Shifts the start of the TFFT period earlier in the symbols. You specify the amount of
TFFT shift as a percentage of the TFFT length.
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7:SYMBol:ADJust <percent>
[:SENSe]:OFDM:CCARrier0|…|7:SYMBol:ADJust?
Example
:OFDM:CCAR0:SYMB:ADJ -3.125
:OFDM:CCAR0:SYMB:ADJ?
Preset -3.125
State Saved Saved in instrument state
Min - The Minimum value of current Guard Interval * 100 %
Max 0
525 Vector Modulation Analyzer Mode User's &Programmer's Reference
