3 VMA Mode
3.2 Custom OFDM Measurement
# Result Unit, if any
13 CC Tx Power dBm
14 All Measured CC Tx Power dBm
15 SNR (MER) dB
16 ccEVM %
17 Valid Points
18 Total Points
19 Improvement Factor dB
If “Report EVM in dB” is set to true, the EVM result is in “dB”
02 Returns the Burst Info results for Component Carrier CC when it is active
# Result Value Range Unit, if any
1 Column Number 5 for current version
2 Row Index
0 Null
1 All
2 Preamble
3 Pilot
4 Unknown Pilot
5 Data
6 Unspecified
3 User1
…
User200
1001
…
1200
4 EVM %
5 Power dB
6 Modulation Format
0 N/A
2 BPSK
3 π/4 BPSK
4 QPSK
5 π/4 QPSK
8 8PSK
16 16QAM
32 32QAM
64 64QAM
Vector Modulation Analyzer Mode User's &Programmer's Reference 410
