Keysight N9020B - 3.5.15 Trace; 3.5.15.1 Select Trace; 3.5.15.2 Trace Control

3 Spectrum Analyzer Mode
3.5 ACP Measurement
3.5.15 Trace
Lets you control the acquisition, display, storage, detection and manipulation of
trace data for the available traces. The Trace Control tab of this menu contains
radio-button selections for the trace type (Clear/Write, Trace Average, Max Hold,
Min Hold) and View/Blank setting for the selected trace.
For the Spectrum Analyzer Mode, when in Single Mode, Measurements and their
Views save the trace data from the last acquisition. This is true for multiple screens.
The marker and trace data will be present whenever the measurement is brought
back into focus. The measurement switches for these measurements do not clear
the traces, so the data will be present until the next acquisition is completed.
3.5.15.1 Select Trace
Specifies the selected trace, which is the trace that will be affected when you
change trace settings.
Select Trace appears above the menu panel, indicating that it applies to all controls
in the menu panel. Select Trace is blanked if you select a tab whose controls do not
depend on the selected trace (for example, Trace Function).
Notes The selected trace is remembered even when not in the Trace menu
Dependencies For the Swept SA measurement:
–
In Image Suppress mode, when you select a trace it becomes the active trace, and the formerly
active trace goes into View
–
When you turn on Image Suppress, Update turns off for all traces except the selected trace
For the ACP measurement, when Meas Method is RBW, FAST or FPOWer, Select Trace is disabled
Preset Trace 1
State Saved Yes
3.5.15.2 Trace Control
The controls on this tab allow you to set the "Trace Type" on page 1927 and its
update mode.
There are four Trace Types:
–
Clear/Write
–
Trace Average
