Operating Math Functions
Table 2-1 presents a summary of the math operations that can be used with each
measurement function.
– All math operations can be toggled on and off by selecting the same math
operation.
– Only one math operation can be turned-on at a time. When selecting another
math operation when one is already on, you are required to turn off the first
operation and then turn-on the second math operation.
– All math operations are automatically turned-off when changing the
measurement functions.
– Range changing is allowed for all math operations.
Table 2-1 Math operations for different measurement functions
Measurement function
Allowed math operations
dBm Rel Min Max Comp Hold %
DCV
DCI
—
Resistance
——
ACV
ACI
—
Frequency
—
Diode/Continuity
——
