Descriptions

S
S
M
M
A
A
R
R
T
T
E
E
R
R
Front Face
(Toward Street)
Shown without mounting
bracket installed
Number Name Description
1 ForwardFacingCamera Usedtorecordscenesthroughthewindshield.
2 SDcardSlot UsedtoinserttheSDcardintounit.
3 EmergencyRecordProtection
CancelButton
Usedtocancelprotectionofalltheemergencyrecordingdata.
4 EmergencyRecordButton Usedtoperformanemer
gencyrecording.
5 VolumeControl Usedtoadjusttheaudiovolumewhenrecording
6 MountingConnection Usedtomatewiththemount.
S
S
M
M
A
A
R
R
T
T
E
E
R
R
Rear Face
(Toward Driver)
Shown without IR installed

Number Name Description
1 StatusDisplay UsedtodisplaythestatusofDriveRecorderortraffic
informationbyusingEnglishtextorsymbols.
2 IRLightConnection UsedtomatewithIRLightmodule.
3 Built‐inSpeaker Providesaudiooutputforchimeandanyinformation.
4 InteriorFacingCamera Recor
dsvideofrominsideyourvehicle.
5 PowerConnectionPort Usedtoconnectthepowercordwiththeunit.
6 SerialNumber Serialnumberoftheunit.
