Functionsofeachcomponent










.








Emergencyrecordbutton(Videoimageremovalprotection)
Inordertorecorddiverdetectedscenesofinterest,presstheemer gencyrecord(E)
buttontorecord.Thisdatarecords1minutebeforeand1minuteafter.(User mayset
pre‐eventtime1minute,2minutesor3minutes).StoredeventrecordingdatainSD
cardwillnotbeerasedunl
essusercancels(Aremotebuttonisalsoprovidedforthis
functionforcovertrecording)Therecordingtimeisdeterminedinprerecordingtime.
SDcardslot
Beforeinserting/removingtheSDcard,PowermustbeOFF.
TheLEDDis
p
la
y
mustbeoff.
(
BLANK!
)
LEDDisplaywindow
Systemstatus—GPSspeed,timeofdayisdisplayedonthismulti‐segmentdisplay.
Alsousedforsystemdiagnostics
Volumecontrol
Adjusttheaudiovolumelevelfordriver’sconvenience.Whenyouturnitleft(<<),it
increasesthevolumewhilearight(>>)turndecreasesthevolume.Audiocanalsobe
turnedoffbysoftwareconfiguration. 
ManualCancellationoftheEmergencyManualRecordifen abledinsoftware
Pressthe“M”buttonforabout3secondsuntilyouhearachimefromthespeaker.
ThisisusedintherarecaseiftheSDcardisfullandwasnotreplaced.Thisfunctionis
typicallynotenabledsotosecureallrecordings.Ifenabledinsystemsetup,allthe
previouseve
ntsandtheoverwritten recordprotectionisdisabledwhenthis button
wasactivated,allowingthesystemtooverwritealarmdata.(rarelyused)
Powerconnectionport
Connectoneendofthecigarettelighterplugcableintothematchingconnectorofthe
powerportoftheunit.Plugtheotherendofthiscabletothecigarette lighterplugof
thevehicle.{Powermaybehardwired(permanentlywired)intotheACC(accessory)
switchedpowerofth
evehicleforamoresecureinstallation.REFERTHISTOTRAINED
PERSONELONLY.Donotlosethesuppliedpowercordoruseothercables.Ifdamaged
orlost
,
contact
y
ourResellerforacablere
p
lacement
Forwardfacingandrearfacing/interiorviewcamera
Thecameramustbealignedhorizontalandvertical.Whenthelensofthecamerais
obstructedorisdirty,clearimagesmaynotbecaptured.Periodiccleaningisrequired.
Tocleanthelens,useasoftcameralensclothtopreventdamage.
