46English
Factory Reset: Remove the top panel
cover to access the Factory Reset button.
To restore factory settings, press and hold
the Factory Reset button for 10 seconds.
Turn the amplifier off and back on by cycling
the ignition.
+
-
+
GND REM +12VGND REM +12V
FADERFADER
-
+
OFF
ON
OFF
ON
+
BRIDGED (L+ AND R-)
CONTROLLER
HI-LEVEL
INPUT
PWR/
PRT
R
L
AMP1 AMP2 OUTPUT
HI-LEVEL
INPUT
PWR/
PRT
R
L
AMP1 AMP2 OUTPUT
- -
WARNING: Factory reset will reset all
settings that are controlled by LXCC to
factory (including crossover)
FADER INPUT Button: Turn the FADER
button ON if you are running more than a
single pair of RCA inputs to the amplifier.
Turn the AMP INPUT button(s) OFF if you
want to drive all channels from a single
input. For example, if you are using both the
AMP1 and AMP2 RCA inputs, switch the
FADER button to ON.
Factory Reset - Press & Hold for 10 seconds
