Kicker LX Series - Lxcc

47English
LXCC
The LXCC is a Control Center that grants
access to the expanded DSP functions of
the LX amplifier, allowing you to fine-tune
your LX with ease.
GND
REM
+12V
GND
REM
+12V
FADERFADER
OFF
ON
OFF
ON
BRIDGED (L+ AND R-)
HI-LEVEL
INPUT
PWR/
PRT
R
L
AMP1
AMP2
OUTPUT
HI-LEVEL
INPUT
PWR/
PRT
R
L
AMP1
AMP2
OUTPUT
CONTROLLER
Once your LX amplifier has been installed,
begin by connecting the RJ-45 cable of
the LXCC to the Controller/Remote Bass
input of the LX amplifier. The center display
will immediately show real-time amplifier
information, including amp model, amp
temperature, and supplied voltage.
