PXIBT100.2 OWNER’S MANUAL
INSTALLATION
Mounting: Choose a structurally
sound location to mount your KICKER
PXIBT100.2. Make sure there are no items
behind the area where the screws will
be driven. Choose a location that allows
at least 4” (10cm) of open ventilation for
the amplifi er. Drill four holes using a 7/64”
(3mm) bit and use the supplied #8 screws
to mount the amplifi er. Mount the unit
behind the fairing, underneath the seat, or
in another secure location isolated from
weather.
PERFORMANCE
Authorized KICKER Dealer:
Purchase Date:
Serial Number:
Model: PXIBT100.2
RMS output @ 4-ohms 25 Watts x 2
RMS output @ 2-ohms 50 Watts x 2
Selectable 12dB high-pass crossover OFF, 60Hz, 80Hz, 120Hz
Frequency response 20Hz – 20kHz (+/- 1dB)
RCA pre-out voltage 4.5V RMS
S/N ratio 90dB
Aux input sensitivity 500mV
USB audio input / charging 5V/1A
Length [in, cm] 7, 17.8
Height [in, cm] 1-5/8, 4
Width [in, cm] 3-7/16, 8.7
Pro Tip: To get the best performance from your new KICKER Amplifi er and extend the warranty by 1 year,
use genuine KICKER accessories and wiring.
IMPORTANT SAFETY WARNING – PROLONGED CONTINUOUS OPERATION OF AN AMPLIFIER IN A DISTORTED OR CLIPPED MANNER
CAN CAUSE YOUR AUDIO SYSTEM TO OVERHEAT, POSSIBLY CATCHING FIRE AND RESULTING IN SERIOUS DAMAGE TO YOUR
COMPONENTS AND/OR VEHICLE. KICKER PRODUCTS ARE CAPABLE OF PRODUCING SOUND LEVELS THAT CAN PERMANENTLY
DAMAGE YOUR HEARING! TURNING UP A SYSTEM TO A LEVEL THAT HAS AUDIBLE DISTORTION IS MORE DAMAGING TO YOUR EARS
THAN LISTENING TO AN UNDISTORTED SYSTEM AT THE SAME VOLUME LEVEL. THE THRESHOLD OF PAIN IS ALWAYS AN INDICATOR
THAT THE SOUND LEVEL IS TOO LOUD AND MAY PERMANENTLY DAMAGE YOUR HEARING. PLEASE USE COMMON SENSE WHEN
CONTROLLING VOLUME.
Mount the PXIBT100.2 using the included screws.
