THREE CHANNEL OPERATION
The higher frequencies (typically above 100Hz) are connected in stereo while the mono
woofer(s) are connected from the left+ to the right-. These systems require the use of
passive crossovers to maintain proper impedance loads at all frequencies.
Left Channel, Right Channel and Subwoofer
TO SOURCE
ZRX Bypass
HIGH-PASS
PASSIVE
CROSSOVER
SYSTEM
CROSSOVER
SUBWOOFER (2Ω Minimum)
KICKER RESOLUTION™ SYSTEM PACK
(1Ω Minimum)
+
+
–
+
–
–
+
–
+
–
+
–
+
–
HIGH-PASS
PASSIVE
CROSSOVER
+
LOW-PASS
PASSIVE
CROSSOVER
SYSTEM
CROSSOVER
+
–
+
–
+
–
–
(System Diagrams, continued)
