Chapter 6 List of Parameters
81
Function
code
Name Descriptions Unit
Factory
setting
Modif
.
Setting
range
d0.09 Motor power 0.0 200.0%(Corresponding to the 0.1% 0.0% * 0 2000
d0.10
Motor estimated frequency
-300.00 300.00Hz 0.01 0.00 * 0 60000
d0.11 Motor actual frequency -300.00 300.00Hz 0.01 0.00 * 0 60000
d0.12 Bus voltage 0 800V 1V 0 * 0 800
d0.13 Drive operation status 0 FFFH
bit0: Run/Stop
bit1: Reverse/Forward
bit2: Operating at zero frequency
bit3: Accelerating
bit4: Decelerating
bit5: Operating at constant speed
bit6: Pre-commutation
bit7: Tuning
bit8: Over-current limiting
bit9: DC over-voltage limiting
bit10: Torque limiting
bit11: Speed limiting
bit12: Drive fault
bit13: Speed control
bit14: Torque control
bit15: Position control(Reserved)
1 0 * 0 FFFFH
d0.14 Inputterminalsstatus 0 FFH 0: OFF 1: ON 1 00 * 0 FFH
d0.15 Output terminals status 0 1FH 0: OFF 1: ON 1 0 * 0 1FH
d0.16 AI1 input -10.00 10.00V 0.01V 0.00 * 0 2000
d0.17 AI2 input -10.00 10.00V 0.01V 0.00 * 0 2000
d0.18 Keyboard potentiometer
input
-10.00 10.00V 0.01V 0.00 * 0 2000
d0.19 Percentage of AI1 after
regulation
-100.00% 110.00% 0.01% 0.00 * 0 20000
d0.20 Percentage of AI2 after
regulation
-100.00% 110.00% 0.01% 0.00 * 0 20000
d0.21 Percentage of Keyboard
potentiometer after
regulation
-100.00% 110.00% 0.01% 0.00 * 0 20000
d0.22 AO1 output 0.0 100.0% (Ratio of the full range) 0.1% 0.0% * 0 1000
d0.23 AO2 output 0.0 100.0% (Ratio of the full range) 0.1% 0.0% * 0 1000
d0.24 Process close-loop
reference
-100.0 100.0%(Ratio of the full range) 0.1% 0.0% * 0 2000
d0.25 Process close-loop
feedback
-100.0 100.0%(Ratio of the full range) 0.1% 0.05% * 0 2000
d0.26 Process close-loop error -100.0 100.0%(Ratio of the full range) 0.1% 0.0% * 0 2000
d0.27 Process close-loop -100.0 100.0%(Ratio of the full range) 0.1% 0.0% * 0 2000
d0.28
Temperature of heatsink 1
0.0 0.0 * 0 1500
d0.29
Temperature of heatsink 2
0.0 0.0 * 0 1500
