Kinetico Reverse Osmosis Compact Series - RO-Compact 1 Parts: Membrane and components

RO Compact Series Technical Manual
42
Part Number Description Pieces
160521 Membrane – Compact Low 3 - 4021 1
170066 Screw - 5 x 12mm 1
170315 Level Stick - 35 Litre 1
170329 Protective Pad - 35 Litre 1
170330 Hanger for Protective Pad 1
170331 Lock Nut - M5 2
170332 Screw - 5 x 16 1
170401 Tube Pu - 12/8 Red 0,70
170447 Elbow - ½” x 12mm 1
170448 Elbow - Push In 12mm 1
170467 Male Base - ø12 x ½” 1
384903 Bottom Plate Compact 1 1
RO-Compact 1 PartsRO-Compact 1 Parts:
Membrane and components
Plastic nut is included with the membrane.
6 x 3mm holes need to be drilled.
170315
170066 170331
170329
170332
170331
170330
170401
170447 170467
170448
384903
