Kinetico Reverse Osmosis Compact Series User Manual

www.kinetico.eu
43
Part Number Description Pieces
170083 Red Shrouded Receptacle 2
170309 Pressure Switch - 1-10 bar, 1/8" 1
660002 Cap Nut - ½" 1
700061 PVC L40mm 1/8" 1
RO-Compact 1 PartsRO-Compact 1 Parts:
With and without by-pass
170151 170151-U
1
Shut o the water.
2
Remove top of solenoid valve, 4 screws.
3
Remove bottom of solenoid valve and
check valve from pipe system.
4
Remove JG connector 18mm and tube.
5
install end cap on pipe system.
6
install pressure switch, PVC fittings
15 x 1/8”.
7
Connect in parallel pressure-switch and
flow-switch with green and yellow wires.
