Speed control R2 – P19
Control of storage tank loading valve – P20
Control of zone loading valve – P21
Control of return increase – P22
Minimum temperature loading circuit – P15
Loading strategy storage tank 1 – P16
Loading strategy storage tank 2 – P17
Speed control R1 – P18
Switch-off temperature differenc
e
heating return increase – P13
Maximum temperature loading circuit – P14
Minimum collector temperature – P11
Switch-on temperature difference
heating return increase– P12
Switch-off temperature difference external hea
t
exchanger – P09
Maximum collector temperature – P10
Switch-off temperature difference solar circuit 2
–
P07
Switch-on temperature difference external heat
exchanger – P08
Switch-off temperature difference solar circuit 1
–
P05
Switch-on temperature difference solar circuit 2
–
P06
Switch-on temperature difference solar circuit 1
–
P04
Only storage tank 2
Maximum temperature storage tank 2 – P02
Storage tank 2 before
storage tank 1
Maximum temperature swimming pool – P03 Only storage tank 1
Maximum temperature storage tank 1 – P01
Parameters
1)
1) Only specific functions and
parameters may be called
up depending on the
selected system.
Priority Factory setting
Storage tank 1 before
storage tank 2
Reset to factory
settings
