Kingspan Temperature differential controller User Manual

38 742.892 | 11.50
EN
Display Characteristic min. max.
Factory
setting
Activation on, oFF
oFF
Output free output R1/R2/R
S
–
Pump type (R1, R2 only) AC, HE
1) 2)
AC
Pump characteristic (HE only) AA, Ab, C (see page p. 16) –
Speed control (R1, R2 only) on, oFF
2)
oFF
Minimum speed (AC only) 30% 100% 50%
Minimum speed (HE + AA only) 0% 100% 25%
Minimum speed (HE + Ab only) 0% 100% 75%
Heat source sensor input 1 ... 5 –
Heat sink sensor input 1 ... 5 –
Switch-on temperature difference
T
diff on
T
diff off
+ 2 K 80 K 6 K
Switch-off temperature difference
T
diff off
0 K T
diff on
– 2 K 3 K
Heat source max. temperature
T
src max.
T
src min.
+ 2 K 180 °C 100 °C
Heat source min. temperature
T
src min.
0 °C T
src max.
– 2 K 0 °C
Heat sink max. temperature T
sink max.
0 °C 95 °C 60 °C
Time restriction on, oFF
oFF
Time window 1 start/end
Time window 2 start/end
Time window 3 start/end
0:00
0:00
0:00
23:59
23:59
23:59
00:00/00:00
00:00/00:00
00:00/00:00
1)
Caution:
Standard pump: Set AC!
High-efficiency pump: Set HE!
2)
Caution:
External consumer (e.g. 230 V relay): Set AC pump type and set the speed control to oFF!
