4
-13DESCRIPTION OF OPERATING SYSTEM
You can select independent PTO op-
eration or ground speed (by transmis-
sion speed ratio) PTO.
To select an operating mode; stop the
tractor completely, reduce the engine
speed to idle, turn PTO clutch switch
to neutral position, depress the clutch
pedal and now select the PTO operat-
ing mode.
(1) PTO Selection Lever
(A) Independent PTO (B) Ground Speed PTO
PTO SELECTION LEVER
S43O428A
(1) PTO Change Lever
PTO CHANGE LEVER
To avoid personal injury:
Disengage PTO, stop engine,
and allow all rotating compo-
nents to come to a complete stop
before connecting, discon-
necting, adjusting, or cleaning
any PTO driven equipment.
!!
!!
!
CAUTION
540 1000rpm
1st 2ndShift
S43O427A
PTO SWITCH(ON/OFF)
Shift the PTO switch to OFF position
prior to starting the engine. If not, the
engine will not started.
(1) PTO switch
(A) - ON (B) - OFF
S43O426A
ON OFF
