KIP 7170K - Manual Feeder Section Jam (Registration Mis-Feed)

Chapter 3 Error Correction 3-6
3. 1. 2 Manual Feeder Section Jam
(Registration Mis-feed)
1. Remove all Print Trays (1).
2. Pull up the Engine Unit Open Levers (2) to open the Engine Unit.
2
2
1
11
Manual Feeder Section
- Registration Mis-feed
