Chapter 1 Before Use 1-5
1. 4 Specifications
Subject Specification
Model KIP 7970
Configuration Console
Printing method Electro photography
Photoconductor Organic Photoconductive Drum
Print speed 160mm per second
(Inch) E: 7 sheets/min D Landscape: 12 sheets/min
(Metric) A0: 7 sheets/min A1 Landscape: 12 sheets/min
Print head LED
Resolution 600dpi x 2400dpi
Print width Maximum 36” (914mm)
Minimum Roll: 11” / 297mm
Cut sheet (Portrait): 8.5” / 210mm
Print length Maximum
(Standard) 6,000mm (bond, 36” / A0 wide only)
or “5 x Standard length” (bond)
“2 x Standard length” (vellum)
“1 x Standard length” (film)
(Option) 24,000mm
Minimum 8.5” (210mm)
NOTE: If the print is longer than the maximum listed above, its
image quality or the reliability of paper feeding is not
guaranteed.
Warm up time Less than 6 minutes
(23 degrees Centigrade, 60% RH and the rated voltage / Bond)
First print time 15.5 seconds (A0 from Roll 1)
Fusing method Roll Fuser
Development method Dry type with non-magnetic mono-component toner
Exposure method LED
Charging method Corona
Transfer method Corona
Separation method Corona
Input power 220V - 240V plus 6% or minus 10%, 50/60Hz, 20A
Power consumption Maximum 3400W or less
Stand by 1300W (Average)
Printing 2500W (Average)
Cold sleep 2.5W
230V, 50/60Hz and Dehumidify Heater is ON
Acoustic noise less than 67db (Printing)
less than 55db (Standby)
Ozone less than 0.05ppm (Average)
Dimensions 1370mm (Width) x 725mm (Depth) x 950mm (Height) (w/o UI)
1702mm (Width) x 725mm (Depth) x 1377mm (Height, max) (w/ UI)
Weight Approx. 390kg
Media (Recommended Media)
US model:
Plain Paper 64g/m
2
to 80g/m
2
, US Bond (PB-20)
Tracing Paper US Vellum (XV-20)
Film 4MIL (PF-4DME)
Europe/Asia model:
Plain Paper 64g/m
2
to 80g/m
2
, Diamond Plain Paper (80g/m
2
)
Tracing Paper Gateway Tracing Paper (73g/m
2
)
Film NSF4MIL Film
(continued on the next page)
