Chapter 1 Before Use 1-7
1. 5 Appearance
1. 5. 1 Front
Name of part Function
1 User Interface (UI) This is a Touch Screen, and many user operations are available.
PLEASE DO NOT push the LCD area too strong.
2 Top Cover Open here to clear the mis-feed paper.
3 Manual Table Open here to insert a cut sheet or to pull the Upper Frame Unit.
4 Roll Decks Each Roll Deck drawer holds 2 rolls of print media.
5 Power Switch You can turn on/off.
1
3
4
5
2
