Chapter 3 Error Correction 3-7
2. Pull out the Upper Frame Unit to your side (front) with holding both handles.
3. Pull up both knobs, and then push the Top Cover to rear side.
Knob Knob
Handle
Upper Frame Unit
Top Cover
Top Cover
Top Cover
